FRAME |
Spark Alloy SL 6011
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
|
FORK |
RockShox Judy Silver TK Solo Air
15x110mm QR axle / 42mm offset / Tapered Steerer
2-Modes / Reb. Adj. / Lockout / 130mm travel
|
REAR SHOCK |
X-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 120-80-Lockout / T165X45mm
|
REMOTE SYSTEM |
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
|
REAR DERAILLEUR |
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
|
SHIFTERS |
Shimano Deore SL-M6100-R / Rapidfire Plus |
CRANKSET |
Shimano FC-MT512-1
55mm CL / 32T
BB-SETShimano BB-MT500 / shell 41x92mm
|
CHAIN |
KMC X12 |
CASSETTE |
Shimano Deore CS-M6100-12 / 10-51 T |
BRAKES |
Shimano MT501 Disc |
ROTOR |
Shimano SM-RT54 CL / F&R 180mm |
H'STEM |
Syncros DC 3.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8"
|
SEATPOST |
Syncros Duncan Dropper Post 2.5
31.6mm / S & M size 125mm / L & XL size 150mm
|
SEAT |
Syncros Tofino 2.5 Regular |
HEADSET |
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
|
HUB (FRONT) |
Shimano HB-MT410-B CL / 15x110mm |
HUB (REAR) |
Shimano FH-MT410-B CL / 12x148mm / Micro Spline |
SPOKES |
Stainless Black 15G / 1.8mm |
RIMS |
Syncros X-30SE / 32H / 30mm |
FRONT TIRE |
Schwalbe Wicked Will / 29x2.4"
Performance / TLR / Foldable / Addix
|
REAR TIRE |
Schwalbe Wicked Will 29x2.4"
Performance / TLR / Foldable / Addix
|
APPROX WEIGHTS IN KG |
14.95 (with tubes) |
APPROX WEIGHTS IN LBS |
32.96 (with tubes) |
MAX. SYSTEM WEIGHT |
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
|
