FRAME
|
Alloy Frame / Virtual 4 link kinematic VLK
27.5" and 29" compatible / geo adj. / Boost 148x12mm
140mm travel / Bosch Gen4 / Integr. removable Battery
Tapered Headtube E2, Central Kickstand Mount
Range Booster Ready |
TRAVEL
|
Front: 140mm / Rear: 140mm |
FORK
|
Marzocchi Z2 Air / eMTB+
Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 140mm travel |
REAR SHOCK
|
X-Fusion NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 140-90-Lockout / 185x50mm |
REMOTE SYSTEM
|
SCOTT TwinLoc Suspension System
3 modes front and rear / integ. Grip clamp |
DRIVE UNIT
|
Bosch Performance CX
EU: 25kmh / INT: 20mph, 85 Nm
|
BATTERY
|
PowerTube 625Wh |
DISPLAY
|
Bosch Purion |
CHARGER
|
4A Charger |
REAR DERAILLEUR
|
SRAM SX Eagle / 12 Speed |
SHIFTERS
|
SRAM SX Eagle Single Click |
CRANKSET
|
FSA CK-320 / 165mm / 34T |
CHAINRING
|
SRAM Eagle 34T DM / Steel |
CHAIN
|
SRAM SX Eagle |
CASSETTE
|
SRAM PG1210 / 11-50 T |
BRAKES
|
Shimano BR-MT520 4 Piston |
ROTOR
|
Front: SM-RT64 CL 203mm / Rear: RT-EM600 CL 203mm |
HANDLEBAR
|
Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 760mm
Syncros Comfort lock-on grips |
H'STEM
|
Syncros FL2.0 / 6061 Alloy
L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8" |
SEATPOST
|
Syncros Duncan Dropper Post 2.5
31.6mm / S size 100mm / M 125mm / L size 150mm / XL 170mm |
SEAT
|
Syncros ER2.5 |
HEADSET
|
Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8"
OD 52/62mm / ID 44/56mm |
HUB (FRONT)
|
Formula CL-811 / 15x110mm |
HUB (REAR)
|
Formula CL-148S / Boost 148x12mm |
SPOKES
|
Stainless Black |
RIMS
|
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready |
FRONT TIRE
|
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual |
REAR TIRE
|
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual |
LIGHTS
|
Bosch Light Cable pre-installed F&R |
APPROX WEIGHTS IN KG
|
23.30 |
APPROX WEIGHTS IN LBS
|
51.37 |
MAX. SYSTEM WEIGHT
|
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage. |
