Frame:
|
Spark RC Carbon HMX
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
|
|
Fork:
|
RockShox SID Ultimate RD3 Air
Custom Race Day Charger 3-Mode Damper
15x110mm Maxle Stealth / 44mm offset /Tapered steerer
Lockout / Reb. Adj. / 120mm travel
|
|
Rear Shock:
|
RockShox NUDE 5 RLC3 Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Ad.j / Debon Air / Reb. Adj./ Travel 120-80-Lockout / T165X45mm
|
|
Remote System:
|
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
|
|
Rear Derailleur:
|
SRAM XX1 Eagle AXS 12 Speed
Wireless Electronic Shift System
|
|
Shifters:
|
SRAM Eagle AXS Rocker Controller
|
|
Crankset:
|
SRAM XX1 Eagle
Carbon crankarm
DUB / 55mm CL / 32T
|
|
BB-Set:
|
SRAM DUB PF 92 MTB Wide / shell 41x92mm
|
|
Chain:
|
SRAM CN XX1 Eagle
|
|
Cassette
|
SRAM XX1 XG1299 / 10-52 T
|
|
Brakes
|
Shimano XTR M9100 Disc
|
|
Rotor
|
Shimano RT-MT900 CL / 180/F and 160/R
|
|
Handlebar
|
Syncros Fraser iC SL XC Carbon
-12° rise / back sweep 8° / 740mm
Syncros Performance XC lock-on grips
|
|
Seatpost
|
FOX Transfer SL Performance Elite Dropper Post
31.6mm / S size 75mm / M, L & XL size 100mm
|
|
Seat
|
Syncros Belcarra 1.0 Regular 1.0
Carbon rails
|
|
Headset
|
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless, +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
|
|
Wheelset
|
Syncros Silverton 1.0S-30 CL
F: 15x110mm, R: 12x148mm
30mm Tubeless ready Carbon rim 28H
DT Swiss 240 Ratchet EXP 36 / XD Driver
SRAM TyreWiz / Syncros SL Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
|
|
Front Tire
|
Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead
Tubeless Ready / EXO
|
|
Rear Tire
|
Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead
Tubeless Ready / EXO
|
|
Extras:
|
SRAM AXS Powerpack
SRAM TyreWiz
|
|
Accessories:
|
Syncros Eco Sealant
Transport Axle
|
|
Approx Weight
|
10.4 kg (Tubeless setup)
|
|
Max. System Weight
|
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
|
