FRAME
|
Spark Alloy SL 6011
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
|
|
FORK
|
RockShox Judy Silver TK Solo Air
15x110mm QR axle / 42mm offset / Tapered Steerer
2-Modes / Reb. Adj. / Lockout / 130mm travel
|
|
REAR SHOCK
|
X-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 120-80-Lockout / T165X45mm
|
|
REMOTE SYSTEM
|
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
|
|
REAR DERAILLEUR
|
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
|
|
SHIFTERS
|
Shimano Deore SL-M6100-R / Rapidfire Plus
|
|
CRANKSET
|
Shimano FC-MT512-1
55mm CL / 32T
|
|
BB-SET
|
Shimano BB-MT500 / shell 41x92mm
|
|
CHAIN
|
KMC X12
|
|
CASSETTE
|
Shimano Deore CS-M6100-12 / 10-51 T
|
|
BRAKES
|
Shimano MT501 Disc
|
|
ROTOR
|
Shimano SM-RT54 CL / F&R 180mm
|
|
HANDLEBAR
|
Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Pro lock-on grips
|
|
H'STEM
|
Syncros DC 3.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8"
|
|
SEATPOST
|
Syncros Duncan Dropper Post 2.5
31.6mm / S & M size 125mm / L & XL size 150mm
|
|
SEAT
|
Syncros Tofino 2.5 Regular
|
|
HEADSET
|
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
|
|
HUB (FRONT)
|
Shimano HB-MT410-B CL / 15x110mm
|
|
HUB (REAR)
|
Shimano FH-MT410-B CL / 12x148mm / Micro Spline
|
|
SPOKES
|
Stainless Black 15G / 1.8mm
|
|
RIMS
|
Syncros X-30SE / 32H / 30mm
|
|
FRONT TIRE
|
Schwalbe Wicked Will / 29x2.4"
Performance / TLR / Foldable / Addix
|
|
REAR TIRE
|
Schwalbe Wicked Will 29x2.4"
Performance / TLR / Foldable / Addix
|
|
APPROX WEIGHTS IN KG
|
14.95 (with tubes)
|
|
APPROX WEIGHTS IN LBS
|
32.96 (with tubes)
|
|
MAX. SYSTEM WEIGHT
|
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
|
